MOBILE RECTIFIERS I2200T48P and I2200T60P

Mobile rectifiers I2200T48P and I2200T60P are used for supplying power to telephone exchanges and other telecom devices in the case of primary power supply system fatal failure. Maintenance service may install mobile rectifier to power telecom equipment until failed power supply system is repaired.

Mobile rectifiers are high performance devices featuring low disturbances, low noise and short response time, fulfilling all requirements set before uninterruptible power supply systems for telecommunication equipment.

I2200T rectifiers are designed for 24 hours autonomous operation, enabling the application in remote locations without crew. May operate with or without batteries.

Rectifier units I2200T are manufactured for 48V and 60V output voltage versions. Upon customer request other output voltages are available. Output power is 2200 W.


Features

  • 2200 W output power - 48 V, 25 A or 60 V, 20 A
  • Fulfills relevant international standards and recommendations: ITU-T, ETSI, ISO, IEC ...
  • Power factor corrected > 0,98
  • Low psophometric noise < 1 mV
  • High efficiency
  • High reliability
  • Does not require preventive maintenance
  • High frequency switchmode power conversion
  • Small volume and weight
  • Self standing device
  • Parallel operation of several units by direct output connection

Applications

  • Emergency power supply of telecom equipment
  • Accu-batteries maintenance
  • Emergency power supply of computer and other professional electronic equipment
  • Temporary power supply of telecom equipment before installation of uninterruptible power supply system
  • Powering telecom and other electronic equipment at fairs, demonstrations, conferences and other

Benefits

  • Extremely robust, resistant to harsh working conditions, specially to damaging input disturbances
  • Based on rectifier units I2200T from S3000 system - verified solutions, simplified maintenance
  • Large LED display with switch for output current or output voltage
  • Fully plug-in installation
  • Extended input voltage range available on request
  • Natural convection cooled
  • Simple adjustment using front panel potentiometer

Easy to handle and install and suitable for transport, mobile rectifier I2200T..P is unavoidable in equipment set of every field maintenance team for telecommunication networks or complex electronic systems. Exceptional resistance to mains voltage disturbances and high reliability enable operation in harsh conditions.

Mobile rectifiers I2200T48P and I2200T60P are modern, highly professional devices, featuring exceptional electrical characteristics, simple handling and high reliability.

Mobile rectifiers I2200T48P and I2200T60P are designed for international market and are available in English, Russian and Serbian versions.

Packaging and accessories set includes elegant two-part box, containing mains cable and load cables with robust crocodile terminations. Accessory set for parallel connection of several mobile rectifiers to achieve higher output power is also available.


Technical data

Input data

Mains voltage Vu   220/230 Veff
Mains frequency   47-63 Hz
Mains voltage range   -15 % to +10 %
Mains distorsion   30 %
Input current   11 А @ Vnom
Inrush current   < 16 А
Power factor cos φ   > 0,98

Input protection

Input fuse   fast 10 А
Overvoltage protection   253 Vac
Undervoltage protection   187 Vac
Surges protection   varistor
Fast overvoltage protection   yes

Output data

Output power   1410 W
Power density   134 W/dm³
Voltage regulation   better than 1 %
Load transient response   1 msec
Load transient overshoot   ±5% @ Δ=50%
Startup/shutdown overshoot   none
Voltage spikes   < 2 Vp-p
Psophometric noise   < 1 mVac
Noise 10Hz-450kHz   < 25 mV
Wideband noise   < 10 mVac/МHz

Output protection

Short circuit protection   yes
Short circuit startup   yes

Output data per version

Feature4860 Unit
Nominal voltage 48 60 Vdc
Output voltage range 49 .. 5761 .. 72Vdc
Nominal current 39 31 Аdc
Current limit 41 33 Аdc
Overvoltage protection 58 .. 6072 .. 75Vdc
Undervoltage protection38 .. 3947 .. 48Vdc

General data

Cooling   natural convection
Efficiency   > 0,9
Temperature range   0 °C .. 45 °C
Storage temperature   -10 °C .. 75 °C
Relative humidity   0 to 90 %
Operating frequency   50 kHz
Startup time   10 msec
Acoustic noise   < 55 dB @ 1 m
Measure/display accuracy   ±1 %
Hot plugin   yes
Service life   40 years
Spare parts and repair   10 years

Safety and other protections

Isolation input/output   2500 Vac
Isolation input/ground   2000 Vac
Isolation output/ground   500 Vac
Isolation resistance   1000 MΩ @ 500 Vdc
Overtemperature protection   yes
Main switch protection   yes

Packaging and accessories

Mains cable   10 m
Load cables   10 m

Outline dimensions and weight

I2200T..PunpackedpackedUnit
Height 300300 mm
Width 130150 mm
Total weight8.510.5kg
Length 400450 mm

Ordering codes

ProductCode
Mobile rectifier I2200T..P E08-IJPB0301-V▲▲-◆◆
Mobile rectifier I2200T..P with packaging and accessoriesE08-IJPB0301-A▲▲-◆◆
Packaging and accessories for I2200T..P E11-IJPA0301-А-◆◆
User documentation for I2200T..P E08-IJPB0301-D01-◆◆
Set for parallel connection I2200T..P E11-IJPA0301-P-◆◆

▲▲ voltage

   48: 48 Vdc, 60: 60 Vdc, 24: 24 Vdc, 110: 110 Vdc

◆◆ language

   SR: serbian, RU: russian, EN: english
